Rockford Fosgate P2D4-12

Rockford Fosgate has always been known as "The PUNCH" and the P2 12" subwoofer certainly continues with the tradition. Kevlar fiber reinforced paper cones deliver bass impact you can feel along with VAST technology to increase surface cone area up to 25%. The P2 subwoofers perform best in standard sealed and vented enclosures. Includes diamond cut cast aluminum trim ring. Optional grille insert available.

FEATURES AT A GLANCE

• High-temp voice coil with spun-laced Nomex® re-inforcement collar
• Dual linear spider with embedded 16 AWG tinsel leads
• Protective PVC textured magnet cover
• Extended pole piece and bumped vented backplate
• StampCast basket with integrated spider venting
• Custom 10-AWG nickel plated push terminals
• Diamond cut cast aluminum trim ring with optional grille
• Kevlar fiber reinforced paper cone
• 1 Year Warranty

Specifications:

• Power Handling (Watts RMS)
• -400 Watts RMS
• -800 Watts Max
• Nominal Impedance: Dual 4-Ohm
• Size: 12"
• Speaker Connector: Dual 10 AWG compression
• Cutout Diameter: 11.22 in. (285 mm)
• Re (Ohms): 6.40
• Qes: 0.59
• Qms: 6.30
• Mounting Depth: 6.40 in. (162 mm)
• Voice Coil Diameter: 2.25" (57.15 mm)
• SPL (dB @ 1w/1m): 86
• Fs (Hz): 27.2
• Qts: 0.54
• Vas (Liters): 81.5
• Xmax (mm): 13.3
• Le (mH): 5.5
• Woofer Displacement: 0.085 cu. ft. (2.4 Liters)
• Magnet Weight (oz): 72.8 oz. (2.06 kg.)
• Sd (cm²): 570
• Subwoofer Type: Standard
• Voice Coil Type: Dual Voice Coil
• Sealed Box Volume (Vb): 1.02 cu. ft. (28.8 Liters)
• Vented Box Volume (Vb): 1.79 cu. ft. (50.6 Liters)
