Punch 12" P1 2-Ohm SVC Subwoofer
P1S2-12
Rockford Fosgate P1 12" are the first in a family of world famous subwoofers called "The Punch". During their inception in the 1980's, they quickly became "The Woofer of Choice" for fanatic car audio systems, with a continued tradition today. Kevlar fiber reinforced paper cones deliver bass impact you can feel, and our VAST technology increases surface cone area up to 25%. Best in standard sealed and vented enclosures. Includes soft touch ABS trim ring.
FEATURES AT A GLANCE
- 1 Year Warranty
- Kevlar fiber reinforced paper cone
- StampCast basket with integrated spider venting
- Rubberized ABS trim ring with optional grille
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Linear spider with embedded 16 AWG tinsel leads
- Extended pole piece and bumped vented backplate
- Custom 10-AWG nickel plated push terminals
- Protective PVC textured magnet cover
Specifications:
- Magnet Weight (oz): 45 oz. (1.28 kg.)
- Voice Coil Type: Single Voice Coil
- Subwoofer Type: Standard
- Re (Ohms): 1.8
- CEA-2031 Compliant
- Voice Coil Diameter: 2.0" (51.6 mm)
- Power Handling (Watts RMS): 250 Watts RMS; 500 Watts Max
- Nominal Impedance: 2-Ohm
- Size: 12"Speaker Connector: Dual 10 AWG compression
- Sd (cm2): 548
- Qts: 0.55
- Vas (Liters): 88.3
- Qms: 3.39
- Qes: 0.84
- Le (mH): 1.17
- Fs (Hz): 25
- Xmax (mm): 9.0
- SPL (dB @ 1w/1m): 86
- SPL (dB @ 2.8v/1m): 89
- Cutout Diameter: 11.22 in. (285 mm)
- Mounting Depth: 6.0 in. (152.4 mm)
- Vented Box Volume (Vb): 1.79 cu. ft. (50.6 Liters)
- Sealed Box Volume (Vb): 1.02 cu. ft. (28.8 Liters)
- Woofer Displacement: .081 cu. ft. (2.3 Liters)
- Shipping Weight:12.5 Lbs. (5.66 Kg)
Punch 12" P1 4-Ohm SVC Subwoofer
P1S4-12
Rockford Fosgate P1 12" are the first in a family of world famous subwoofers called "The Punch". During their inception in the 1980's, they quickly became "The Woofer of Choice" for fanatic car audio systems, with a continued tradition today. Kevlar fiber reinforced paper cones deliver bass impact you can feel, and our VAST technology in the Punch P1 woofer increases woofer surface cone area by up to 25%. Best in standard sealed and vented enclosures. Includes soft touch ABS trim ring.
FEATURES AT A GLANCE
- Kevlar fiber reinforced paper cone
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Linear spider with embedded 16 AWG tinsel leads
- Custom 10-AWG nickel plated push terminals
- StampCast basket with integrated spider venting
- Rubberized ABS trim ring with optional grille
- Extended pole piece and bumped vented backplate
- 1 Year Warranty
- Protective PVC textured magnet cover
Specifications:
- Power Handling (Watts RMS)
- -250 Watts RMS
- -500 Watts Max
- Voice Coil Type: Single Voice Coil
- Subwoofer Type: Standard
- Nominal Impedance: 4-Ohm
- Le (mH): 3.01
- Voice Coil Diameter: 2.0" (51.6 mm)
- Magnet Weight (oz): 45 oz. (1.28 kg.)
- Size: 12"
- Speaker Connector: Dual 10 AWG compression
- Fs (Hz): 25
- Qts: 0.55
- Qes: 0.56
- Xmax (mm): 9.0
- Qms: 3.40
- Vas (Liters): 88.3
- Re (Ohms): 3.6
- Sd (cm2): 548
- SPL (dB @ 1w/1m): 86
- SPL (dB @ 2.8v/1m): 89
- Cutout Diameter: 11.22 in. (285 mm)
- Mounting Depth: 6.0 in. (152.4 mm)
- Woofer Displacement: 0.081 cu. ft. (2.3 Liters)
- Sealed Box Volume (Vb): 1.02 cu. ft. (28.8 Liters)
- Vented Box Volume (Vb): 1.79 cu. ft. (50.6 Liters)
- Shipping Weight: 11.7 Lbs. (5.3 kg)
