Kenwood X302-4
Kenwood X302-4
Regular price
$200.00 USD
Regular price
Sale price
$200.00 USD
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
"X series" 4ch Amplifier with 50W x 4 @ 4ohms, 75W x 4 @ 2ohms, 600W Maximum Power
4-channel car amplifier
50 watts RMS x 4 at 4 ohms (75 watts RMS x 4 at 2 ohms)
150 watts RMS x 2 bridged at 4 ohms (4-ohm stable when bridged)
CTA-2006 compliant
Class D amp technology
variable high- and low-pass filters (50-200 Hz, 12 dB/octave)
variable bass boost on B channels (0-18 dB at 40 Hz)
preamp and speaker-level inputs
wiring and hardware not included with amplifier
8-gauge power and ground leads recommended
fuse rating: 20A x 2
8-7/16"W x 2-1/8"H x 5-15/16"D
Specifications:
RMS Power Output (Watts x Channels) - 50 x 4
Peak Power Output (Watts x Channels) - 150 x 4
Power at 2 Ohms (Watts x Channels) - 75 x 4
Bridged Power (Watts x Channels) - 150 x 2
Minimum Impedance Bridged - 4
Minimum Impedance Unbridged - 2
Best Frequency Response - 20 50k Hz
THD at Rated RMS Power - 1%
Signal to Noise Ratio - 85 dB
Input Voltage - 14.4v
Amplifier Class - D
Low-Pass Crossover Frequency - 50-200 Hz
Low-Pass Slope (dB/octave) - 12 dB/octave
High-Pass Crossover Frequency - 50-200 Hz
High-Pass Slope (dB/octave) - 12 dB/octave
Bass Boost - 0-18 dB
Bass Boost Frequency - 40 Hz
Fan Cooled - No
Fuse Rating - 40
Speaker Level Inputs Harness
Preamp Outputs - No
Width (inches) - 8-7/16
Height (inches) - 2-1/8
Depth (inches) - 5-15/16
4-channel car amplifier
50 watts RMS x 4 at 4 ohms (75 watts RMS x 4 at 2 ohms)
150 watts RMS x 2 bridged at 4 ohms (4-ohm stable when bridged)
CTA-2006 compliant
Class D amp technology
variable high- and low-pass filters (50-200 Hz, 12 dB/octave)
variable bass boost on B channels (0-18 dB at 40 Hz)
preamp and speaker-level inputs
wiring and hardware not included with amplifier
8-gauge power and ground leads recommended
fuse rating: 20A x 2
8-7/16"W x 2-1/8"H x 5-15/16"D
Specifications:
RMS Power Output (Watts x Channels) - 50 x 4
Peak Power Output (Watts x Channels) - 150 x 4
Power at 2 Ohms (Watts x Channels) - 75 x 4
Bridged Power (Watts x Channels) - 150 x 2
Minimum Impedance Bridged - 4
Minimum Impedance Unbridged - 2
Best Frequency Response - 20 50k Hz
THD at Rated RMS Power - 1%
Signal to Noise Ratio - 85 dB
Input Voltage - 14.4v
Amplifier Class - D
Low-Pass Crossover Frequency - 50-200 Hz
Low-Pass Slope (dB/octave) - 12 dB/octave
High-Pass Crossover Frequency - 50-200 Hz
High-Pass Slope (dB/octave) - 12 dB/octave
Bass Boost - 0-18 dB
Bass Boost Frequency - 40 Hz
Fan Cooled - No
Fuse Rating - 40
Speaker Level Inputs Harness
Preamp Outputs - No
Width (inches) - 8-7/16
Height (inches) - 2-1/8
Depth (inches) - 5-15/16
