Rockford Fosgate PMX-5CAN
Rockford Fosgate PMX-5CAN
Regular price
$379.99 USD
Regular price
Sale price
$379.99 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Rockford Fosgate's PMX-5CAN is an AM/FM/WB tuner and digital media receiver with 2.7" full color display with CAN bus functionality. Features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using PMX-CAN.
The PMX-5CAN digital media receiver is designed for marine and motorsports systems.
The PMX-5CAN features a 2.7"full color TFT display for optimum viewing - even in full sun - that is optically wet bonded to prevent any dust or moisture penetration. It is IPX6 rated and uses a water resistant rotary encoder knob with white LED button illumination and front mounted sub level controls. Additionally, with features such as SiriusXM and Pandora capabilities, Bluetooth audio steaming with album art support for Apple and Android products and true 2 zone/2 source control, this unit becomes a true command center of any system.
Output flexibility comes a 4x50W @ 2ohm internal amplifier or dual zone output RCA's allowing the addition of after-market amplifiers for more power and output. Add in the EEPROM memory system, custom GUI interface and wired remote expansion capabilities and you have the only media receiver you'll ever need. The PMX-5CAN also features CANbus functionality for connection to Raymarine MFD (Multi-Function Display) systems using the PMX-CAN adaptor (see Accessories tab.)
ISO8846/SAE J1171 Ignition Protection Certified
Stainless Steel Rear Chassis
Steering Wheel Control Interface Compatible
Pandora Internet Radio
SiriusXM-Ready™
A2DP and AVRCP Bluetooth Wireless Streaming
FCC, CE, IC, and C-Tick Certified
Multi Region Radio Frequencies
Low Voltage Warning Alert
AUX and USB Inputs with USB Charging
On Board Punch EQ Control
Independent Subwoofer Level Control
Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
IPX6 Marine Grade
7-Band Graphic EQ
2.7" full color display w/ auto dimming backlightning
Zone Control: 2 Zone / 2 Source (F/R/S + F)
AM / FM / WB Tuner
CANbus (Controller Area Network) compatible. Requires PMX-CAN accessory
Compatible with a Multi-Funtion Display using NMEA2K entertainment standard. See our MFD Compatibility Chart
*Antenna not included
2 Year Warranty
Specs
FM TUNER:
Frequency Range 87.9-107.9 MHz
FM TUNER
Sensitivity 8 dB
AM TUNER
Usable Sensitivity 40 dB
RCA Output Voltage 4V
Operating Voltage 10.5 V - 16 V
Fuse Rating 15 A
MEDIA PLAYER:
Audio Format Compatibility MP3, WMA
TUNER N/A
Speaker Outputs
(Yes/No)Yes
Made for iPod Models:
iPod Touch (5th generation)
iPod Touch (4th generation)
iPod Nano (7th generation)
iPod Nano (6th generation)
Android Compatibility
Bluetooth® Only
RCA OUTPUTS N/A
Device TypeDigital-Media Receiver
SiriusXM-Ready®
(Yes/No)Yes
Requires SXV300
Pandora® Internet Radio
(Yes/No)Yes
RCA Frequency Response87.5 MHz - 107.9 MHz
WB TUNER:
Frequency Range162.40 - 162.55
(US & Canada)
TUNER
Number Of Presets 18 FM / 12 AM / 6 WB
USB Output Current 1A
USB Charging
(Yes/No)Yes
Frequency Response20 Hz - 20 kHz
Made for iPhone Models:
iPhone 7 Plus
iPhone 7
iPhone 6s Plus
iPhone 6s
iPhone 6 Plus
iPhone 6
iPhone 5S
iPhone 5C
iPhone 5
iPhone 4S
iPhone 4
iPhone 3GS
Apple®/Android™ Compatible
(Yes/No)Yes
AM TUNER:
Frequency Range 530 kHz - 1710 kHz
RCA Output Impedance 500Ω
Speaker Impedance 2-Ohms
Power Output:
CEA-2006 Guidelines CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω Peak
≤1.0% THD+N
Dimensions:
(HxWxD)Width 8" (20.3cm)
Face Depth 1.5" (3.8cm)
Mount Depth 7.1" (18.2cm)
Height 3.5" (8.9cm)
Chassis to Face Top 0.9" (2.3cm)
Chassis to Face Bottom 0.59" (1.5cm)
USB Capacity:
32Gb max
999 Folders max
999 Songs max
Clock
(Yes/No)No
Display Size2.7” Color TFT
Bluetooth®
(Yes/No)Yes
3.0+EDR, A2DP 1.3
USB Version2.0
Steering Wheel Control Ready
(Yes/No)Yes
Multi-Zone/Multi-Source
(Yes/No)Yes
Compatible Remotes:
PMX-1R
PMX-0R
(3 Remote Limit, 100 ft Total Wired Distance)
AUX Input
(Yes/No)Yes
