Rockford Fosgate R2-500X1
Rockford Fosgate R2-500X1
Regular price
$279.99 USD
Regular price
Sale price
$279.99 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Rockford Fosgate's Prime Series R2-500X1 amplifier can power your subwoofer with up to 500 watts RMS. You can adjust the low-pass filter, infrasonic filter, and Rockford Fosgate's famous Punch boost to get the best possible bass from the sub and enclosure in your vehicle.
mono subwoofer amplifier
300 watts RMS x 1 at 4 ohms
500 watts RMS x 1 at 2 ohms
CTA-2006 compliant
Class-D amplifier design
variable low-pass filter (50-250 Hz, 12 dB/octave)
variable bass boost (0-18 dB at 45 Hz)
variable subsonic filter (15-40 Hz, 12 dB/octave)
C.L.E.A.N. gain setup system includes clip lights
wired remote Punch Level Control included
auto remote turn-on
preamp and speaker-level inputs
preamp outputs
wiring, fuse, and hardware not included with amplifier
4-gauge power and ground leads and an 80-amp fuse recommended
dimensions: 8-1/2"W x 2"H x 7-3/4"D
warranty: 1 year
Specifications:
RMS Power Output (Watts x Channels) - 300 x 1
Power at 2 Ohms (Watts x Channels) - 500 x 1
Minimum Impedance Unbridged - 2
Best Frequency Response - 20-250 Hz
THD at Rated RMS Power - 1%
Signal to Noise Ratio - 75 dB
Input Voltage - 14.4v
Amplifier Class - D
Low-Pass Crossover Frequency - 50-250 Hz
Low-Pass Slope (dB/octave) - 12 dB/octave
Bass Boost - 0-18 dB
Bass Boost Frequency - 45 Hz
Fan Cooled - No
Fuse Rating - 80
Speaker Level Inputs Harness
Preamp Outputs - 1 pair
Width (inches) - 8-1/2
Height (inches) - 2
Depth (inches) - 7-3/4
